Boat jetty grating dimensions: 250x250x20 mm, hot-dip galvanised
$50.00*
% $84.64* (40.93% saved)Available now, delivery time: Lieferzeit 1-2 Werktage
Product information "Boat jetty grating dimensions: 250x250x20 mm, hot-dip galvanised"
made from S235JR (St37-2), hot-dip galvanised
with flat bar edging
Length (in the direction of the bearing bars): 250 mm
Width (in the direction of the infill or U-profile): 250 mm
Grating height: 20 mm
Bearing bar (height/material thickness): 20/2 mm
Weight: 5.35 kg
Point load on 100 mm² load cube 2.43 kN (243 kg)
Product note: Hot-dip galvanising is intended for corrosion protection and is not a surface finishing process. Due to the nature of the process, irregularities may occur in the zinc coating.
Galvanisation in accordance with DIN EN ISO 1461
| Höhe: | 20 mm |
|---|---|
| Länge: | 250 mm |
| Breite: | 250 mm |
Product safety (GPSR)
Manufacturer / responsible person in the EU: FeNau GmbH, Veit-Stoß-Str. 20, 90579 Langenzenn, Germany · info@fenau.eu · +49 911 97917230
Safety information: metal products may have sharp edges – wear protective gloves. Observe permissible loads and installation instructions; secure components properly before use.
