Boat jetty grating dimensions: 500 x 500 x 25 mm, hot-dip galvanised
Product information "Boat jetty grating dimensions: 500 x 500 x 25 mm, hot-dip galvanised"
Made from S235JR (St37-2), hot-dip galvanised
with flat bar edging
Length (support bar direction): 500 mm
Width (filler or U-profile direction): 500 mm
Grating height: 25 mm
Support bar (height/material thickness): 25/2 mm
Weight: 11.36 kg
Point load on 100 mm² load cube: 1.67 kN (167 kg)
Product note: Hot-dip galvanising is intended for corrosion protection and is not a surface finishing process. Due to the nature of the process, irregularities may occur in the zinc coating.
Galvanising in accordance with DIN EN ISO 1461
| Höhe: | 25 mm |
|---|---|
| Länge: | 500 mm |
| Breite: | 500 mm |
Product safety (GPSR)
Manufacturer / responsible person in the EU: FeNau GmbH, Veit-Stoß-Str. 20, 90579 Langenzenn, Germany · info@fenau.eu · +49 911 97917230
Safety information: metal products may have sharp edges – wear protective gloves. Observe permissible loads and installation instructions; secure components properly before use.
