Bottom roller, double-bearing, roller diameter 45 mm MEA 10337630
FeNau Ltd
$49.28*
Available now, delivery time: Lieferzeit 1-2 Werktage
Lagerbestand:
1007
Product number:
60.0197.7
EAN:
4251412907685
Gewicht:
1.54 kg
Description
Product information "Bottom roller, double-bearing, roller diameter 45 mm MEA 10337630"
Bottom roller, double-bearing – roller diameter 45 mm
High-quality roller made from S235JR steel, electro-galvanised – ideal for use in sliding gate systems and other heavy-duty applications.
- Material: S235JR steel, electro-galvanised
- Roller diameter: 45 mm
- Load capacity per roller: 160 kg
- Rail width: 10 mm
Dimensions at a glance
| Designation | Dimension |
|---|---|
| Dimension a | 23 mm |
| Dimension a1 | 6 mm |
| Dimension b | 53 mm |
| Dimension b1 | 20 mm |
| Dimension d | 45 mm |
| Dimension d1 | 35 mm |
| Dimension d2 | M 10 |
| Dimension Rb | 10 mm |
| Item number | 010337630 |
Eigenschaften
| Durchmesser: | Ø 45 mm |
|---|---|
| Form: | Laufrolle |
