Glass support bracket, Ø 30 mm, V2A, connection: pipe Ø 42.4 mm

FeNau Ltd

$8.72*

Prices exclude VAT and are subject to delivery charges

Available now, delivery time: Lieferzeit 5-10 Werktage

Stk

Stock: 394

Product number: 10.5042.4

EAN: 4251412927935

Length: 28 mm

Weight: 0.09 kg

20,000 items in stock

CAD data available after login

Over 200,000 satisfied customers

Worldwide delivery

Product information "Glass support bracket, Ø 30 mm, V2A, connection: pipe Ø 42.4 mm"

Glass point holder, Ø 30 mm, for 42.4 mm connection

Made of stainless steel 1.4301/V2A/AISI 304
Diameter: 30 mm, with M8 x 45 mm
threaded screw Clamping range: 6.0 – 16.76 mm
Glass bore: min. 16 mm
Rubber pad thickness: 2 mm
Suitable for indoor and outdoor use

Durchmesser:	Ø 30 mm
Werkstoff:	V2A
Ø Für Rohr \| Ø Außendurchmesser \| Ø Anschluss:	Ø 42.4mm (11⁄4″)

Product safety (GPSR)

Manufacturer / responsible person in the EU: FeNau GmbH, Veit-Stoß-Str. 20, 90579 Langenzenn, Germany · info@fenau.eu · +49 911 97917230

Safety information: metal products may have sharp edges – wear protective gloves. Observe permissible loads and installation instructions; secure components properly before use.

All product safety information → · Your legal guarantee rights →
